Display System
Display System: SXRD panel, projection system
Display device
Size of effective display area:0.61” x 3
Number of pixels: 6,220,800 (1920 x 1080 x 3) pixels
Projection lens
Focus: Manual
Zoom: Manual (Approx. x1.6)
Lens shift: Manual, Vertical: +/- 71%, Horizontal: +/- 25%
Light source
Light source: High-pressure mercury lamp, 215 W type
Recommended lamp replacement time *1
Recommended lamp replacement time: 6000 H (Lamp mode: Low)
Filter replacement cycle (Max.): Same time as the lamp replacement is recommended
Screen size
Screen size: 40” to 300” (1,016 mm to 7,624 mm)
Light output
Light output: 1800 lm (Lamp mode: High) *2
Colour light output
Colour light output: 1800 lm (Lamp mode: High) *2
Displayable scanning frequency
Horizontal: 19 kHz to 72 kHz
Vertical: 48 Hz to 92 Hz
Display resolution
Computer signal input: Maximum display resolution: 1920 x 1080 dots (HDMI Input only)
Video signal input: 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i
The following items are available for HDMI input only.
1080/60p, 1080/50p, 1080/24p
OSD languages
OSD languages: 17-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic, Polish)
INPUT OUTPUT (Computer / Video / Control)
HDMI1 / HDMI2: Digital (RGB/Y Pb/Cb Pr/Cr)
Remote: RS-232C, D-sub 9-pin (female)
IR IN: Mini Jack
USB: DC 5V, Max. 500 mA
Acoustic noise
Acoustic noise: 22 Db
Operating temperature / Operating humidity
Operating temperature / Operating humidity: 5°C to 35°C (41°F to 95°F) / 35% to 85% (no condensation)
Storage temperature / Storage humidity
Storage temperature / Storage humidity:-20°C to +60°C (-4°F to +140°F) / 10% to 90% (no condensation)
Power requirements
Power requirements: AC 240 V, 3.1 A to 1.3 A,50/60 Hz
Power consumption
AC 220 V to 240 V: Max 310 W
Power consumption (Standby Mode)
AC 220 V to 240 V: 0.4 W (when "Remote Start" is set to "Off")
Power consumption (Networked Standby Mode)
AC 220 V to 240 V: 1.0 W (LAN) (when "Remote Start" is set to "On")
Standby Mode / Networked Standby Mode Activated
Standby Mode / Networked Standby Mode Activated: After about 10 Minutes
Dimensions (W x H x D) (without protrusions)
407.4 x 179.2 x 463.9 mm
16 1/8 x 7 1/8 x 18 3/8 inches
Mass
Mass: Approx. 9 kg / 20 lb
