Sensor Resolution
Effective: 14.2 Megapixel
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Internal Recording Modes
XAVC
3840 x 2160 at 1/2/3/4/6/8/12/15/23.98/25/29.97 fps [60 to 100 Mb/s]
1920 x 1080p at 1/2/3/4/6/8/12/15/23.98/25/29.97/50/59.94/100/240/250/480/500/1000 fps [35 to 50 Mb/s]
1920 x 1080i at 50/59.94 fps [25 to 50 Mb/s]
1280 x 720 at 50/59.94 fps [50 Mb/s]
AVCHD
1920 x 1080p at 1/2/3/4/6/8/12/15/23.98/25/29.97/50/59.94/100/240/250/480/500/1000 fps [24 to 28 Mb/s]
Show More
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC
Video I/O
1x HDMI (Unspecified Signal) Output
1x BNC (Composite) Output
1x BNC (3G-SDI) Output
Mobile App Compatible
No
Battery Type
Sony V-Series
Imaging
Sensor Resolution
Effective: 14.2 Megapixel
Image Sensor
1"-Type CMOS
Image Stabilization
Optical in Integrated Lens
Built-In ND Filter
Mechanical Filter Wheel with 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Capture Type
Video Only
Exposure Control
Shutter Type
Electronic Rolling Shutter
Shutter Speed
1/10000 to 1/6 Second
Gain
-3 to 33 dB
Minimum Illumination
1.7 Lux at 1/30 Shutter Speed
White Balance
2300 to 15,000K
Lens
Focal Length
9.3 to 111.6mm (35mm Equivalent: 29 to 348mm)
Optical Zoom Ratio
12x
Max Digital Zoom
48x
Minimum Aperture
f/2.8 to 4.5
Minimum Focus Distance
Wide: 0.4" / 1.0 cm
Telephoto: 39.4" / 100.1 cm
Filter Size
62 mm
Control Rings
Focus
Zoom
Focus Control
Autofocus
Manual Focus
Video Capture
Internal Recording Modes
XAVC
3840 x 2160 at 1/2/3/4/6/8/12/15/23.98/25/29.97 fps [60 to 100 Mb/s]
1920 x 1080p at 1/2/3/4/6/8/12/15/23.98/25/29.97/50/59.94/100/240/250/480/500/1000 fps [35 to 50 Mb/s]
1920 x 1080i at 50/59.94 fps [25 to 50 Mb/s]
1280 x 720 at 50/59.94 fps [50 Mb/s]
AVCHD
1920 x 1080p at 1/2/3/4/6/8/12/15/23.98/25/29.97/50/59.94/100/240/250/480/500/1000 fps [24 to 28 Mb/s]
Fast-/Slow-Motion Support
Yes
Built-In Microphone
Stereo
Audio Recording
2-Channel 24-Bit 48 kHz
IP Streaming
H.264, RTMP, RTMPS
1280 x 720 (3.0 Mb/s)
640 x 360 (1.0 Mb/s)
Interface
Media/Memory Card Slot
Dual Slot: SD/SDHC/SDXC
Video I/O
1x HDMI (Unspecified Signal) Output
1x BNC (Composite) Output
1x BNC (3G-SDI) Output
Audio I/O
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
2x XLR 3-Pin Mic/Line (+48 V Phantom Power) Input
Power I/O
1x Barrel Input
Other I/O
1x Micro-USB
1x Micro-USB Control
1x 2.5 mm Sub-Mini (LANC) Control
Wireless
2.4 / 5 GHz Wi-Fi 5 (802.11ac)
NFC
Mobile App Compatible
No
Global Positioning (GPS, GLONASS, etc.)
No
Monitor
Display Type
Articulating Non-Touchscreen LCD
Display Size
3.5"
Resolution
1,560,000 Dot
Viewfinder
Type
Built-In Electronic (OLED)
Size
0.39"
Resolution
2,360,000 Dot
Focus
Focus Type
Auto and Manual Focus
Focus Mode
Automatic, Manual Focus
Environmental
Storage Temperature
-4 to 40°F / -20 to 60°C
General
Battery Type
Sony V-Series
Power Consumption
6.9 W
Shoe Mount
1x Cold Shoe
Tripod Mounting Thread
1/4"-20 Female
Dimensions (W x H x D)
5.1 x 7.1 x 11.3" / 130 x 181.5 x 287 mm
Weight
2.2 lb / 1020 g
