Product TypeCamcorder - 4K
Lens IncludedLeica
Effective Video Resolution1.549 MP
Widescreen Video CaptureYes
Camcorder Media TypeFlash card
Optical Sensor TypeMOS
Optical Sensor Size4/3"
Optical Zoom13 x
Digital Zoom10 x
Image StabilizerOptical
Auto FocusTTL contrast detection
Digital Video FormatAVCHD, H.264, MOV
Image Recording FormatJPEG
Max Video Resolution4096 x 2160
Audio Signal FormatLinear PCM
Interfaces ProvidedComposite video/audio, HDMI, balanced audio, 3G HD-SDI, USB 3.0
Min Illumination0.2 lux
Exposure ModesProgram, automatic
White BalanceCustom, automatic, presets
White Balance Presets3200K, 5600K, 2000K - 15000K
Max Shutter Speed1/8000 sec
Min Shutter Speed1/25 sec
Gain Selection+12 dB, +18 dB, +20 dB
TypeLeica 13 x zoom lens - 12.8 - 167 mm - f/2.8
Focal Length Equivalent to 35mm Camera28 - 365.3mm
Focus AdjustmentAutomatic, manual
Min Focus Distance3.3 ft
Zoom AdjustmentMotorized drive, manual
Filter Size72 mm
FeaturesBuilt-in 1/4 neutral density filter, built-in 1/64 neutral density filter, built-in 1/16 neutral density filter
Low Lux / Night ModeYes
Additional FeaturesBuilt-in speaker
Viewfinder TypeLCD - LCD
Viewfinder Color SupportColor
Viewfinder Diagonal Size0.39"
Viewfinder Resolution2,360,000 pixels
Type4.3" LCD display
Resolution2,760,000 pixels
Display Form FactorRotating (270°)
Microphone Operation ModeStereo
Connector Type1 x 3G HD-SDI input ( BNC ) 1 x composite video/audio output ( BNC ) 1 x HDMI output ( 19 pin HDMI Type A ) 2 x balanced audio input ( 3 pin XLR ) 1 x headphones ( mini-phone stereo 3.5 mm ) 1 x audio output ( mini-phone stereo 3.5 mm ) 1 x remote control ( mini-phone 3.5 mm ) 1 x remote control ( sub-mini phone 2.5 mm ) 1 x timecode in ( BNC ) 1 x USB 3.0 ( 5 pin Micro-USB Type B ) 1 x DC power input
Memory Card SlotDual SD card
Memory Card SlotDual SD card
Supported Memory CardsSD Memory Card, SDXC Memory Card, SDHC Memory Card, SDHC UHS-I Memory Card, SDXC UHS-I Memory Card
Memory Card Max Supported Size128 GB
Width7.1 in
Depth8.5 in
Height14.7 in
Weight5.95 lbs
Min Operating Temperature32 °F
Max Operating Temperature104 °F
BrandPanasonic
Part NumberAG-DVX200PJ
GTIN00885170254657
