Canon C70 Specs
Imaging
Lens Mount Canon RF
Lens Communication Yes, with Autofocus Support
Sensor Resolution Actual: 9.6 Megapixel (4206 x 2280)
Effective: 8.85 Megapixel (4096 x 2160)
Sensor Type 26.2 x 13.8 mm (Super35) CMOS
Pixel Pitch 6.4 µm
Image Stabilization Digital, 5-Axis
Built-In ND Filter Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64), 8 Stop (1/256), 10 Stop (1/1024) ND Filters
Capture Type Stills & Video
Exposure Control
Shutter Type Electronic Rolling Shutter
Shutter Speed 1/12 to 1/2000 Second
ISO Sensitivity Photo/Video
160 to 25,600 (Extended: 100 to 102,400)
Gain -6 to 54 dB (Native)
-2 to 54 dB (Expanded)
Shutter Angle 11 to 360°
Advertised Dynamic Range 16 Stops
White Balance 2000 to 15,000K
Presets: AWB, Daylight, Set A, Set B, Tungsten
Internal Video Capture
Recording Modes XF-AVC 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
UHD 4K (3840 x 2160) at 24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
HD (1280 x 720) at 23.976p/24.00p/25p/29.97p/50i/50p/59.94i/59.94p [24 to 410 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 119.88p
UHD 4K (3840 x 2160) at 119.88p
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit
DCI 2K (2048 x 1080) at 179.82p
Full HD (1920 x 1080) at 179.82p
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [24 to 35 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [24 to 35 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [135 to 225 Mb/s]
UHD 4K (3840 x 2160) at 50p/59.94p [135 to 225 Mb/s]
2840 x 1080 at 23.976p/24.00p/25p/29.97p/50p/59.94p [50 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [50 Mb/s]
HD (1280 x 720) at 50p/59.94p [12 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 10-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 to 170 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [100 to 170 Mb/s]
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
HD (1280 x 720) at 50p/59.94p [9 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 10-Bit
DCI 4K (4096 x 2160) at 119.88p
UHD 4K (3840 x 2160) at 119.88p
DCI 2K (2048 x 1080) at 179.82p
Full HD (1920 x 1080) at 179.82p
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:0 8-Bit
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [150 Mb/s]
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p [150 Mb/s]
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p [35 Mb/s]
HD (1280 x 720) at 50p/59.94p [8 Mb/s]
H.264/H.265/MP4/XF-AVC/XF-AVC Proxy 4:2:2 8-Bit
DCI 4K (4096 x 2160) at 119.88p
UHD 4K (3840 x 2160) at 119.88p
DCI 2K (2048 x 1080) at 179.82p
Full HD (1920 x 1080) at 179.82p
Sensor Crop Modes Super35 / APS-C
2K (2048 x 1080)
Variable Frame Rates DCI 4K: 12 to 119.88 fps
DCI 2K (Windowed): 12 to 179.82 fps
Gamma Curve Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Wide DR
Recording Limit Unlimited
Video System NTSC/PAL
Built-In Microphone Type Stereo
Mono
Audio Recording 4-Channel 24-Bit 48 kHz LPCM Audio
External Video Capture
External Recording Modes 4:2:2 10-Bit via HDMI
DCI 4K (4096 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p
UHD 4K (3840 x 2160) at 23.976p/24.00p/25p/29.97p/50p/59.94p
Full HD (1920 x 1080) at 23.976p/24.00p/25p/29.97p/50p/59.94p
DCI 2K (2048 x 1080) at 23.976p/24.00p/25p/29.97p/50p
HD (1280 x 720) at 23.976p/24.00p/25p/29.97p/50p/59.94p
IP Streaming Yes
Still Image Capture
Image Sizes JPEG
4096 x 2160
3840 x 2160
2048 x 1080
1920 x 1080
Aspect Ratio 16:9
Image File Format JPEG
Bit Depth 12-Bit
Interface
Media/Memory Card Slot Dual Slot: SD/SDHC/SDXC
Video I/O 1 x HDMI Output
Audio I/O 2 x Mini XLR Mic/Line (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm TRS Stereo Input
1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O 1 x Barrel (11.5 to 20 VDC) Input
Other I/O 1 x USB Type-C Control/Video Input/Output
1 x BNC (Timecode) Input/Output
1 x 2.5 mm Sub-Mini (LANC) Control
Wireless None
Global Positioning (GPS, GLONASS, etc.) GPS
*Adapter Required
Monitor
Size 3.5"
Resolution 2,760,000 Dot
Display Type Articulating Touchscreen LCD
Focus
Focus Type Auto and Manual Focus
Focus Mode Automatic (A), Continuous-Servo AF (C), Manual Focus (M)
