Product TypeCamcorder - 1080p
Lens IncludedBody only
Camcorder Sensor Resolution9.84 Mpix
Effective Video Resolution8.29 Mpix
Widescreen Video CaptureYes
Camcorder Media TypeFlash card
Optical Sensor TypeCMOS
Optical Sensor Size13.8 x 24.6 mm
Image ProcessorDIGIC DV III
Digital Video FormatMPEG-2, MXF
Image Recording FormatJPEG
SensitivityF10
Signal to Noise Ratio (typical)54 dB
Audio Signal FormatLinear PCM
FeaturesSMPTE Color Bars, selectable frame rates, SMPTE Time Code, zebra pattern, vectorscope, waveform monitor
AV InterfacesComposite video/audio, HDMI, S-Video
Light SensitivityISO 320-20000
Min Illumination0.25 lux
Exposure ModesManual
White BalanceCustom, automatic, presets
White Balance PresetsTungsten light, daylight, 2000K - 15000K (100K steps)
Max Shutter Speed1/2000 sec
Min Shutter Speed1/24 sec
Gain Selection0 to +24 dB in 0.5 dB, -6 to +30 dB in 3 dB
Built-in ND Filters1/4, 1/64, 1/16
Lens System MountingCanon EF
Low Lux / Night ModeYes
Status LCD Display IlluminationYes
Status LCD Display InformationFrame counter, film speed, memory card status, white balance indicators, picture resolution, battery condition
Additional FeaturesRGB primary color filter, digital noise reduction, progressive scanning, interval shooting mode, Pre-Rec function, Relay Recording, built-in cooling fan, 24p Cinema Mode, peripheral illumination correction, high-speed recording, frame recording mode, Canon Log Gamma mode, rolling shutter artifacts reduction, fast motion recording
Viewfinder TypeElectronic
Viewfinder Color SupportColor
Viewfinder Diagonal Size0.52"
Viewfinder Resolution1,555,000 pixels
Field Coverage100%
Dioptric Correction Range-5.5 to +2
Image Aspect Ratio16:9
FeaturesViewfinder brightness control, tilting
Type4" LCD display
Resolution1,230,000 pixels
Display FeaturesRotating
Connector Type1 x HD/SD-SDI output 1 x HDMI output 1 x composite video/audio output 2 x balanced audio input 1 x microphone 1 x headphones 1 x Genlock TC input / output Remote control 1 x DC power input
Memory Card SlotCompactFlash Card, SD card
SoftwareDrivers & Utilities
Included AccessoriesEyepiece cover, body cap, shoulder strap, eyecup, camera grip, LCD color monitor, camcorder handle, tripod adapter base, power adapter with battery charger
ProtectionSplashproof, dust resistant
Battery TypeCanon BP-955
Details1 x Li-ion rechargeable battery - 5200 mAh ( included )
Memory Card SlotCompactFlash Card, SD card
Supported Memory CardsCompactFlash
Video CaptureMPEG-2 - 1920 x 1080 - 50Mbps MPEG-2 - 1280 x 720 - 50Mbps MPEG-2 - 1920 x 1080 - 35Mbps MPEG-2 - 1280 x 720 - 35Mbps MPEG-2 - 1440 x 1080 - 25Mbps
Width5.2 in
Depth6.7 in
Height7 in
Weight3.2 lbs
